Telescopic Belt Conveyor

Cut unloading time in half,Improve turn-around time,Improve the working environment,Short period of investment payback,Tailored according to the requirement.

Contact

FEATURES

Cut unloading time in half

Fast loading and unloading

Improve turn-around time

Reduce the waiting time of trailer,minimize the turnover time.

Improve the working environment

Short the handing distance and reduce labor intensity

Short period of investment payback

More than 16,000 pieces of parcels can be loading or unloading each day.It was proved by practice that;The investment returns are usually obtained in less than 2 years.

Tailored according to the requirement

A variety of functions can be configured for the telescopic belt conveyor,Such as:hydraulic lifting,combine with DWS system,Droopsnoot and ground rails.

MODEL

Model	Base part（L1）	Extended part（L2）	Total length（L）	Height（A）	Profile width（B）	Belt width（C）
3 Sections
RD T3 2.5/2.7	2500	2700	5200	555	C+345	600/800
RD T3 3/4	3000	4000	7000	555	C+345	600/800
RD T3 4/5.4	4000	5400	9400	555	C+345	600/800
RD T3 4.5/6	4500	6000	10500	555	C+345	600/800
RD T3 5/7	5000	7000	12000	555	C+345	600/800
RD T3 6/8.4	6000	8400	14400	555	C+345	600/800
4 Sections
RD T4 4/7	4000	7000	11000	725	C+390	600/800
RD T4 5/10	5000	10000	15000	725	C+390	600/800
RD T4 6/12.3	6000	12300	18300	725	C+390	600/800
RD T4 7/15	7000	15000	22000	755	C+390	600/800
RD T4 7.5/16	7500	16000	23500	755	C+390	600/800
5 Sections
RD T5 6/16	6000	16000	22000	850	W1+440	600/800
RD T5 7.5/21	7500	21000	28500	850	W1+440	600/800

Loading / unloading trailers and trucks of any size is twice as fast as manual handling

Health and safety legislation becomes increasingly more stringent,which makes it sound economic sense to consider whether the loading and unloading equipment you invest in limits the risk of accidents to personnel and damage to goods.

OPTIONS

01-Hydraulic system

The two hydraulic cylinders are used to adjust the height of the telescopic belt conveyor,so as to get a best operating height.

02-Front light

Provide the best working environment for the operation area lighting,We are equipped with safetyenergy-saving LED lights.

03-Floor Mounted Rails

Increase flexibility by using a mobile Telescopic belt conveyor to serve multiple loading bays.Typically rails are fitted in parallel,so they lie flush with the floor.

04-Joystick

The operator can control the lifting(hydraulic is needed)and the expanding of conveyor by joystick.The left and right end of machine can be equipment with a joystick,so that the right hand and left hand operator can operate freely

05-Other choice

Belt width:600mm or 800mm

Belt reversible

Customer specified color

Adjustable transmission speed

DETAILED DESCRIPTION

Technical data

Belt width:600mm or 800mm
Belt model:Forbo Siegling PVC/PVK beld
Belt direction:Direction of loading or unloading
Drive:SEW gearmotor
Load：50kg/m
Powersupply：3 x 380VAC, 50Hz，The power supply is located at the back of the telescopic belt conveyor,and the opreating switch is located in the front part.
Install temperature：0-40°C
Environment：Humidity35-85% rH
Noise：65dB(A)This is the maximumvalue,measuring distance :1m

Design

Through the analysis of finite element mechanics,the telescopic belt conveyor's structure is more reasonable,and can withstand the harsh handling environment.The safety protection is adopted for all moveable parts,and has reached latest safety standard.The double bearing telescopic device helps the belt be expanded with the robot arm at the same time,The telescopic belt conveyor's performance is implicit during the whole period of using.
Color：The color can be selected according to the requirement of customers.
Control panel：Can be equipped at the front or left front and right front side of the machine.
Joystick：Equipped in the front side of the machine.The machine expands when push the pole,and stops when release the pole to ensure the safety.
Safety features：The emergency stop button is located at the front end and back end of the machine.The safety pop-up roller islocated at the front of the machine.
Signal exchanging:The telescopic belt conveyor can exchange signals with package processing system.
